Versatile Lovol M404R tractor 40 HP diesel engine
- Engine model : Doosan D18
- Standard emissions : Stage V / EPA4F
- Power : 29.41 kW / 40 hp
Lovol M404R Tractor
The Lovol M404R Tractor is a versatile and robust agricultural machine, designed to meet the needs of field work. Equipped with a 4WD system, it offers great stability and power, ideal for difficult terrain. In addition, it includes counterweights that improve its balance and performance in different agricultural tasks.
This model has a speed range of 1.97 to 29.67 km/h and eight gears both forward and reverse, which provides great versatility to adjust to different jobs. The transmission with mechanical differential and wet disc brakes ensure safe driving and excellent control in all circumstances.
The rear independent power take-off (PTO) offers 540 and 1000 rpm options, allowing various implements to be engaged efficiently. The 260/70R16 front and 320/85R24 rear tires provide optimal ground adherence, making the Lovol M254CR a reliable tool for intensive agricultural work.
Roof not included as standard, available as an accessory.
Technical specifications
Engine model | Doosan D18 |
Standard Emissions | Stage V / EPA4F |
Power | 29.41 kW / 40 hp |
Metering speed | 2350 r/min |
Maximum torque | 160 N-m |
Displacement | 1800 cc |
Air filter | Dry type 38 |
Fuel tank capacity | 26 L |
Drive | 4x4 |
Clutch | 10-inch, dry, double-acting |
Transmission management mode | Slip gear / synchronizer with shuttle gear |
Number of gears | 8+8 |
Speed range | 1.97 to 29.67 km/h |
Reverse Range | 1.74 to 26.33 km/h |
Differential Lock | Mechanical |
Brake Type | Wet Disc |
Parking brake | Parking brake |
Flow rate | 24 L/min |
Number of hydraulic valves | 2 pairs |
Elevator control | Position control |
Lifting capacity | 8.5 kN (at 610 mm from lower balls) |
Pulling device | U-type hitch |
Traction | Swinging drawbar |
PTO type | 540/1000 rear independent |
PTO shaft | 6 splines |
Front tire | 260/70R16 |
Rear tire | 320/85R24 |
Length* Width* Height | 3558 x 1550 x 2450 mm |
Wheelbase | 1800 mm |
Shipping weight | 1624 kg |
IMPORTANT NOTICE |
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending. |
Data sheet
- Power Supply
- Diesel
- Displacement
- 1800 cc
- Power
- 40 HP
- Traction
- 4x4
- Road traffic
- Approved
