Side shredder for tractor GEO ITALY AGFN open hood

Rating:
(0)
  • Weight : 550 - 710 kg
  • Power supply : PTO tractor
  • Working width PTO : 140 - 220 cm
  • Cardan shaft : Yes
  • Robustness : Medium
  • Min. tractor power : 50 - 80 HP
  • Number of hammers : 12 - 22
  • Country of manufacture : Italy
  • CARDAN SHAFT INCLUDED
En stock
Extras
Extras
Precio total de la opción:
icon Shredder type
Shredder type
Shredder with side arm
icon Type of cut
Type of cut
Hammers
icon Working width PTO
Working width PTO
140 - 220 cm
icon Tractor power
Tractor power
50 - 80 HP
icon Cardan shaft
Cardan shaft
Included
icon Type of coupling
Type of coupling
Pantograph displacement
icon Displacement
Displacement
Hydraulic
icon Robustness
Robustness
Medium-Heavy
icon Number of hammers
Number of hammers
12 - 22
icon Country of manufacture
Country of manufacture
Italy
icon Weight
Weight
550 - 710 kg
€3,463.51 excl. VAT
- 4%
€3,324.97 excl. VAT
€4,023.21 VAT incl.
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Side shredder for tractor GEO ITALY AGFN open hood
€4,023.21
Extras
Extras
Precio total de la opción:
Select
Qty

Side shredder for tractor GEO ITALY AGFN

The GEO ITALY AGFN tractor side shredder with its opening hood offers easy access for maintenance and adjustments. Equipped with chains and rubber protection, it ensures durability in challenging terrain, while the adjustable tensioner and side guides allow it to adapt to different conditions.

Its CE safety features, such as mudguards and double cylinder to move the mulcher, ensure reliable use. In addition, its gearbox with cast iron freewheel and external impact protection make it strong and durable.

With a universal three-point hitch, it is versatile and can be adapted to various types of tractors, providing safe and efficient operation thanks to standard anti-shock valves that guarantee greater protection.

Features

Model AGFN 140 AGFN 160 AGFN 180
Working width 140 cm 160 cm 180 cm
Tractor power (HP) 50-80 50-80 50-80
Tractor power (KW) 37-60 37-60 37-60
Weight 568 kg 598 kg 654 kg
Hammers 12 14 16
Belts 4 4 4
Model AGFN 200 AGFN 220
Working width 200 cm 220 cm
Tractor power (HP) 50-80 50-80
Tractor power (KW) 37-60 37-60
Weight 698 kg 728 kg
Hammers 18 22
Belts 5 5

Dimensions


Model AGFN 140 AGFN 160 AGFN 180 AGFN 200 AGFN 220
A (cm) 86 86 86 86 86
B (cm) 82 102 122 142 162
C (cm) 168 188 208 228 268
D (cm) 140 140 140 140 140
E (cm) 200 220 240 260 300
Dimensiones Trituradora

Inclination

IMPORTANT NOTICE
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending.

259468

Data sheet

Shredder type
Shredder with side arm
Type of cut
Hammers
Working width PTO
140 - 220 cm
Tractor power
50 - 80 HP
Cardan shaft
Included
Type of coupling
Pantograph displacement
Displacement
Hydraulic
Robustness
Medium-Heavy
Number of hammers
12 - 22
Working width (cm)
140 - 149 cm
160 - 169 cm
180 - 189 cm
200 - 209 cm
220 - 229 cm
Country of manufacture
Italy
Weight
550 - 710 kg

Specific References

mpn
3.37.140.3
New
