Inverter welder Gala gar Atlantic 200 MMA 200 A


  • Current : Single phase
  • Type of Welder : MMA / TIG
  • Weight : 5,2 Kg
  • No load voltage : 63 V
  • Service 40ºC : 35 %
  • Regulation range : 10 - 200 A
  • TIG type : TIG lift
En stock
icon Current
Current
Single-phase
icon Typology Welder
Typology Welder
MMA / TIG
icon No-load voltage
No-load voltage
63 V
icon Service 40ºC
Service 40ºC
35 %
icon Regulating range
Regulating range
10 - 200 A
icon Usable electrodes
Usable electrodes
1 - 4 mm
icon TIG type
TIG type
TIG lift
icon Weight
Weight
5.2 Kg
€332.39 excl. VAT
- 4%
€319.09 excl. VAT
€386.10 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Finance in 3 months with no interest Pago PAYPAL
Shipments to all Europe
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


Inverter welder Gala gar Atlantic 200 MMA 200 A
€386.10
Qty

Inverter welder Gala gar Atlantic 200 MMA 200 A

The inverter welder Gala gar Atlantic 200 MMA is a versatile and powerful tool designed for various processes such as MMA and TIG DC Lift. With a capacity to handle electrodes up to 4 mm in diameter, it is ideal for metalworking, maintenance and repair applications, offering optimum performance in MMA welding.

Its compact and lightweight design makes it easy to transport, without sacrificing power. With advanced features such as Hot Start, Arc Force and Antisticking, it ensures high quality and precision welding. In addition, its DC TIG welding capability with Lift-Arc priming expands the possibilities for use in different projects.

The 35/50 mm welding connectors allow an efficient and stable connection, making this machine portable and reliable for DC stick electrode MMA and DC TIG welding. The built-in inverter technology ensures efficient and consistent performance.

Accessories

  • Grounding cable.
  • Electrode holder clamp.

Technical data sheet

Supply voltage (U1-I 50/60 Hz) 1Ph 230V ± 10%
Effective power (S1max eff) 9.4 KVA
Vacuum voltage (U2o) 65 V
Continuous regulation range MMA (I2min - I2max) 10 - 200 A
Maximum coated electrode diameter 4.0 mm
Duty cycle factor (I2 max ; tc=5' ; Tamb=40ºC) 200 A / 35%
Degree of mechanical protection IP IP 21
Thermal protection degree F (155 ºC)
Weight 5,2 Kg
Dimensions 130x206x351 mm
