The DHY16KE open three-phase 1,500 RPM generator set offers a robust and efficient solution for a variety of power needs. With a power rating of 15 KVA / 12 kW and emergency power of up to 16.5 KVA, this generator is ideal for consistently supporting heavy loads. Its advanced control system includes alarms for low oil pressure, high temperature and low battery, ensuring optimal performance and increased safety during use.
Equipped with a digital display that makes it easy to read parameters such as fuel level, frequency and working hours, the DHY16KE provides vital information for efficient management. In addition, it features a simplified liquid drainage system thanks to its 1/4-turn valve and easy forklift access, making it easy to transport and maintain.
This generator has a low sound level of 66 dBA at 75% load, making it suitable for noise-sensitive environments. Its autonomy at 100% is 15.4 hours, with an efficient consumption of 5 L/h at full load. With a standard tank capacity of 78 L, it is a reliable choice for long working days without the need for frequent refills.
| MODEL | DHY16KE |
| Frequency (Hz) | 50 |
| Rotation speed (r/min) | 1.500 |
| Power Factor | 0,8 |
| Rated Power (KVA/KW) | 15 KVA / 12 kW |
| Emergency Power (KVA) | 16,5 KVA |
| Rated Current (A) | 21,6 A |
| Noise Level (7m, 75% load) (dBA) | 66 dBA |
| Autonomy at 100% | 15,4 h |
| Consumption at 100% load (L/hours) | 5 L/h |
| Radiator coolant capacity (L) | 7 L |
| Standard tank capacity (L) | 78 L |
| HYUNDAI engine model | HY485 |
| Rated power at 1,500 rpm (kW) | 17 kW |
| Number of cylinders | 4 |
| Aspiration | Natural |
| Oil sump capacity (L) | 6 L |
| Displacement (cc) | 2.200 cc |
| Model | 164D |
| Degree of protection | IP23/H |
| Weight (Kg) | 490 Kg |
| Dimensions (cm) | 156 x 90 x 98 cm |
| IMPORTANT NOTICE |
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
| The batteries included in some machines are a free gift, so they are exempt from warranty. |
| This generating set allows to request, with a surcharge, a tank extension of 500L, 1000L or 1500L through our customer service. |
