Powerful tractor Hanwo 704R 75 HP
- Diameter x Stroke : 78×86 mm
- Rated / max. power : 55,8 kW / 75 HP
- RPM speed (nominal/max.) : 2200 rpm
€30,785.91 VAT incl.
The Fieldtrac 918 diesel mini tractor It features a 900 cubic centimeter water-cooled four-stroke engine capable of delivering 18 horsepower. As for its transmission system, this mini tractor features a synchronized mechanical gearbox with a single dry clutch.
The Mini tractor Fieldtrac 918 comes equipped with electric start that operates with a 12 V battery with a capacity of 73 Ah and a 12 V starter motor with 1.6 kW of power. The system of power steering with which this mini tractor is equipped is hydraulic and it should be mentioned that it has a 3-point hitch CAT-1.
Highlight that the Fieldtrac 918 It has a series of features such as a battery disconnect switch, silencer under the hood or a mobile charging point.
In relation to its weight and dimensions, the Fieldtrac 918 diesel mini tractor It has an approximate weight of 900 kilograms with dimensions of 282 x 109.7 x 230.6 centimeters. The Wheelbase It is 1420 mm and the turning radius of this machine is 2.3 meters.
ENGINE | |
Model | K3CE5 |
Emission standard | Stage-V |
Type | naturally aspirated 4-stroke water-cooled diesel |
Number of cylinders | 3 |
Engine power | 18.5 HP |
HP (Horsepower) | 16 |
Nominal RPM | 2700 |
Diameter and path | 70 x 78 mm |
Displacement | 900 cc |
Air purifier | Double dry-type filter |
Fuel tank capacity | 18 liters |
TRANSMISSION | |
Clutch | Dry Individual |
Type of gearbox | Synchronized mechanics |
No. of Gears | 6F+2R |
Gear lever position | Displacement |
Speed Range - Km/h |
|
Rear Differential Lock | Standard |
Type of Brake | Dry Drum |
Type of Transmission | 4WD |
PTO (rpm) | 540 and 900 RPM |
Electricity | |
Battery | 12 V, 73 AH, (700 CCA) |
Headlight | 4 Projector Lamps |
Starting System | 12 V Starter Motor, 1.6 KW |
Alternator | 12V, 35 AMP |
HYDRAULIC SYSTEM | |
Type of control | ADDC |
Pump Capacity | 12.9 LPM |
Maximum Lifting Capacity | 500 Kg |
3-Point Hitch | CAT-1 |
Steering System | Hydraulic Power Steering |
Rear Coil Value | 2 Values with Quick Anchoring |
DIMENSIONS AND OTHER CHARACTERISTICS | |
Total Dimensions (LxBxH) with TPL and Front Ballast | 2820 x 1097 x 2306 mm |
Distance to the Ground | 190 mm |
Turning Radius | 2.3 meters |
Weight | 918 |
Wheelbase | 1420 mm |
Way of the Wheels |
|
Front Weight/Ballast (standard) | 60 kg |
Rear Wheel Ballast (optional) | 60 kg |
Tire Options (Front and Rear Size) |
|
Driver's seat | Adjustable Seat of European Design |
Operating Environment | 10 - 45ºC |
Mobile Charging Point | Yes |
Silencer (Under the Hood) | Yes |
Battery Cut-Off Switch | Yes |
ROPS | Yes |
Pull-up bar | Optional |
Hitch Set | Yes |
Hood Lock with Special Key | Yes |
IMPORTANT NOTICE |
Mandatory on the part of the client, review oil levels and lubrication before startup. If the goods cannot be checked at the time of receipt, it should be noted on the carrier's sheet that the customer is in agreement. except for pending exam. |
