Fixed high-volume crusher Zeppelin Grand Canyon 540 PTO


  • Working width: 1000 - 1190 mm
  • Power requirement: 50-100 Hp
  • Weight: 480 - 580 kg

CARDAN SHAFT INCLUDED

Assembly and set-up INCLUDED
En stock
icon Shredder type
Shredder type
Rear shredder
icon Type of cut
Type of cut
Hammers
icon Working width PTO
Working width PTO
100 - 119 cm
icon Tractor power
Tractor power
50 - 100 HP
icon Cardan shaft
Cardan shaft
Included
icon Type of coupling
Type of coupling
Fixed hitch
icon Robustness
Robustness
Medium
icon Number of hammers
Number of hammers
8 - 10
icon ✔️
✔️
Rear rakes
icon Includes
Includes
Interfila Disc
icon Weight
Weight
480 - 520 kg
€2,757.64 excl. VAT
- 7%
€2,564.61 excl. VAT
€3,103.17 VAT incl.
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Fixed high-volume crusher Zeppelin Grand Canyon 540 PTO
€3,103.17
Select
Qty

Shredder Zeppelin Grand Canyon

The Zeppelin Grand Canyon shredders are capable of shredding up to 15 cm thick, are designed to shred all types of branches and stubble and are perfect for generating biomass for pruning fruit trees in small to medium size orchards.

In addition, the Grand Canyon shredders include an adjustable gate and an 8 to 9 mm plate that comes with a 10 mm thick rotor support. A cardan shaft is included.

Features

Models ESTRGV100AP ESTRGV120AP ESTRGVD120AP
Working width 1000 mm 1190 mm 1190 mm
No. of belts 5 5 5
No. hammers 8 10 10
No. of stubble cultivators 7 8 8
Rotor diameter 168 mm 168 mm 168 mm
Power requirement 50-100 50-100 50-100
PTO 540 540 540
Brushcutting disc No No Yes
Weight 480 Kg 480 Kg 520 + 60
Dimensions 1050 x 1160 x 1100 mm 1050 x 1350 x 1100 mm 1050 x 1350 x 1100 mm
IMPORTANT NOTICES
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement , unless there is a pending examination.

Interesting links

    Related products

    157028

    Data sheet

    Shredder type
    Rear shredder
    Type of cut
    Hammers
    Working width PTO
    100 - 119 cm
    Tractor power
    50 - 100 HP
    Cardan shaft
    Included
    Type of coupling
    Fixed hitch
    Robustness
    Medium
    Number of hammers
    8 - 10
    ✔️
    Rear rakes
    Working width (cm)
    100 - 109 cm
    110 - 119 cm
    Includes
    Interfila Disc
    Weight
    480 - 520 kg

    Specific References

    mpn
    ESTRGV100AP
    New

    ✔️ Advantages of making purchases in the Spanish territory

    • National warranty: By purchasing from authorized distributors throughout Spain, you are assured of receiving a 100% Spanish warranty for your products.
    • Local after-sales service: In case of any inconvenience or need for after-sales service, you will have a more efficient and accessible support when purchasing within Spain.

    ❌ Disadvantages of buying outside Spanish territory

    • Complicated warranty management: Buying products outside Spain can make warranty management difficult, as there may be problems with the Spanish serial number or delays in the process.
    • Limited after-sales service: The availability of after-sales service may be limited or less accessible when purchasing products abroad.
    • Tax declaration: When purchasing products outside Spain, customers may be required to make an additional tax declaration, such as an intra-community purchase, which may involve additional tax formalities.
