Universal inter-row disc with feeler 63 cm Zeppelin 4 hoses
- Adaptable to any machine
- Double blade disc
- Perimeter protection
€1,606.69 VAT incl.
CARDAN SHAFT INCLUDED
Shredder GEO ITALY EFGCH OT with hydraulic side shift of 35 cm that allows the rotor to approach trees, poles and ditches without invading the crop line. Ideal for fruit vineyards and farm maintenance where you want to reach the edges with a single pass.
Robust construction with cast iron gearbox with freewheel that protects the transmission. The reinforced chassis and the toothed counter blade increase shredding capacity on weeds and pruning debris for a finer residue.
Uniform finish on any terrain thanks to the adjustable rear roller with scraper that maintains constant working height even on wet floors. Adjustable belt tensioner ensures smooth turning and long belt life.
Designed to work safely. Incorporates front skirts and side skids that control projections and improve support on the ground. All protections comply with CE standards.
Quick assembly with three-point linkage category I and cardan shaft support. It can be equipped with hammers or Y-blades depending on the type of vegetation and the desired speed. A version with manual displacement is available on request.
Model | EFGCH 125 OT | EFGCH 145 OT | EFGCH 155 OT |
Working width | 125 cm | 145 cm | 155 cm |
Total width | 135 cm | 155 cm | 165 cm |
Tractor power (HP) | 25-40 | 25-40 | 30-40 |
Tractor power (KW) | 18-29 | 18-29 | 22-37 |
Weight | 240 kg | 270 kg | 285 kg |
Hammers | 20 | 24 | 24 |
Belts | 2 | 2 | 3 |
Model | EFGCH 165 OT | EFGCH 175 OT | EFGCH 185 OT |
Working width | 165 cm | 175 cm | 185 cm |
Total width | 175 cm | 185 cm | 200 cm |
Tractor power (HP) | 40-60 | 40-60 | 40-60 |
Tractor power (KW) | 30-44 | 30-44 | 30-44 |
Weight | 300 kg | 315 kg | 335 kg |
Hammers | 28 | 28 | 32 |
Belts | 3 | 4 | 4 |
Model | EFGCH 195 OT | ||
Working width | 195 cm | ||
Total width | 210 cm | ||
Tractor power (HP) | 40-60 | ||
Tractor power (KW) | 30-44 | ||
Weight | 340 kg | ||
Hammers | 32 | ||
Belts | 4 |
IMPORTANT NOTICE |
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending. |
This tractor shredder includes a hammer cutter system. You also have the option of ordering a blade system by calling our customer service department. |
Data sheet
Specific References
At Intermaquinas, we make sure that your agricultural machinery always works at 100%. We offer a complete after-sales service that covers any possible incident with your equipment.
Whenever there is a warranty or factory defect, your machine will be covered: 1 year for professionals and 2-3 years for individuals. We take care of everything: we or the carrier will pick up the machinery and send it to the factory for repair or, if necessary, replacement.
To solve minor problems in the most agile way, we have our online mechanics service. Our specialized mechanics will guide you step by step over the phone to solve the breakdown quickly and easily, avoiding unnecessary trips. Intermaquinas recommends greasing after each operation to ensure perfect performance and extend the life of the machines.
If the problem is more complex or cannot be solved with telephone assistance, we take care of everything. We pick up your machine and take it to our workshop, where our specialized mechanics will repair it, whether it is light or heavy machinery. We know that many technical services are far away and that a van is not always available for transport. Carrying it by car can be uncomfortable, as well as entailing the risk of scratches or dirt. Therefore, with our pick-up service you save time and complications, ensuring that your equipment arrives in perfect condition for repair.
Our team of specialists is available to ensure that your machinery is always in the best condition. Contact us and we will help you with the fastest and most effective solution.
