Hammer Brush Cutter Bertolini BTS 80 Honda Engine
Hammer Brush Cutter Bertolini BTS 80 Honda Engine
Hammer Brushcutter Bertolini BTS 80 Honda Engine-2
Hammer Brush Cutter Bertolini BTS 80 Honda Engine
Hammer Brush Cutter Bertolini BTS 80 Honda Engine
Hammer Brush Cutter Bertolini BTS 80 Honda Engine

Hammer Brush Cutter Bertolini BTS 80 Honda Engine 10.7 Hp


  • Honda GX 340 engine
  • Gearbox: 4 speeds (3 forward + 1 reverse)
  • Working width 80 cm
  • Power 10.7 HP
En stock
icon Type of cut
Type of cut
Of hammers
icon Power Supply
Power Supply
Gasoline
icon Working width
Working width
80 cm
icon Startup
Startup
Manual
icon Engine
Engine
Honda
icon Engine model
Engine model
GX 340
icon Power
Power
10.7 HP
icon Engine type
Engine type
4 strokes
icon Gears
Gears
3+1
icon Differential lock
Differential lock
Yes
icon Traction
Traction
Self-propelled
icon Transmission type
Transmission type
Oil bath gears
icon spin
spin
Assisted
icon Number of blades Y
Number of blades Y
46
icon Weight
Weight
175 kg
€4,098.81 excl. VAT
- 4%
€3,934.86 excl. VAT
€4,761.18 VAT incl.
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


Hammer Brush Cutter Bertolini BTS 80 Honda Engine 10.7 Hp
€4,761.18
Qty

Hammer Brushcutter Bertolini BTS 80 Honda GX 340 Engine

The hammer brushcutter Bertolini BTS 80 has a Honda GX 340 engine with a power of 10.7 HP. This model of hammer brushcutter Bertolini offers a working width of 80 cm and an adjustable height between 20 and 80 mm.

It also has extreme versatility thanks to its gearbox. It has four speeds, three forward and one reverse. The dimensions of this hammer brushcutter model are 1216 mm x 1657 mm x 964 mm.

The BTS 80 hammer brushcutter operates by transmission with gears in oil bath. It has a tensioned belt clutch and independent steering with wheel block.

The hammer brushcutter has a cutting unit with a 46-blade "Y " shaped rotor. This model uses locking swivel wheels for the front wheels and 16/6.50-8" wheels on the rear wheels. It weighs only 175 kg.

This powerful hammer brushcutter model guarantees excellent cleaning of the soil, orchards and vineyards. Thanks to its efficient and powerful cutting unit and the large working width we can perform an excellent cleaning.

Features

Engine Honda GX 340
Gearbox 4 speeds, 3 front + 1 rear
Working width 80 cm
Power 10.7 HP
Transmission Oil bath gears
Cutting height 20 - 80 mm, crankshaft adjusted
Cutting unit Rotor with 46 "Y" shaped knives
Weight 175 kg
Dimensions 1216 mm x 1657 mm x 964 mm

Videos of assembly and operation

Difference between the oil bath clutch of other brands and the dry multi-disc clutch of other brands Bertolini

Oil immersed clutch brake (Other brands) Disadvantages

  • Hydraulic due to the use of oil.
  • When the machine fills with debris it is more prone to failure.
  • Practical and functional with good maintenance when needed.
  • First time use requires an oil change in a maximum of 40 hours.
  • The engine has a small oil pump which communicates with the clutch device and lubricates it and makes it work. When this oil is full of debris, the system will stop working and start to fail.
  • In the case of poor maintenance the machine starts to fail. The warranty does not cover the damage so it will be necessary to take it to the workshop and have it done by a professional.
  • In certain points of the machine there could be oil leaks.

Multi-disc dry clutch Bertolini

  • Simpler and more mechanical system and the clutch with brake and a force multiplication system without DHS.
  • This machine is less prone to failures

IMPORTANT
It is mandatory for the customer to check oil and grease levels before start-up !
