PTO Generator Carod TF-40 40 kVA

Rating:
(0)
  • Stabilization : AVR
  • Power : 40 kVA
  • Current : Three-phase
  • Weight : 370 kg
  • Power supply : PTO tractor
En stock
icon Power Supply
Power Supply
PTO tractor
icon Tractor power
Tractor power
60 HP
icon Stabilization
Stabilization
AVR
icon Power (kVA)
Power (kVA)
40 kVA
icon Current
Current
Three-phase
icon Weight
Weight
370 kg
€3,185.96 excl. VAT
- 4%
€3,058.52 excl. VAT
€3,700.81 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


PTO Generator Carod TF-40 40 kVA
€3,700.81
Qty

Genset PTO Carod TF-40 40 kVA

The PTO generator set Carod TF-40 with a continuous power of 42 kVA at 40ºC and 48 kVA in standby mode at 27ºC. Equipped with electronic voltage regulator-AVR, it ensures a stable output.

With a power factor of 0.8 and IP23 protection, it is suitable for challenging environments. Its short-circuit current of 3 times the rated current for 20 seconds guarantees safety.

Operating at 50 Hz with a LINZ alternator, this 40 kVA three-phase generator set is connected in star-series and has 4 poles for efficient performance. Its 60+ HP tractor engine ensures durability.

Features

Power 40 kVA
Phases Three phase
Voltage 400 V
Revolutions 1500 rpm
Frequency 50 Hz
Alternator LINZ
Tractor > 60 HP
Connection type Star-Series
No. of phases 3
No. of poles 4
Power ^T= 125 °C, 40ºC at CONTINUOUS 42 kVA
Power ^T= 163 °C, 27ºC on STANDBY 48 kVA
Power factor 0,8
Insulation class / ^Temp H/H
Protection class IP23
Short-circuit current (for 20sec) 3 x In
Voltage regulator Electronico-AVR
IMPORTANT NOTICE
The customer is obliged to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement , unless an inspection is pending.

258733

Data sheet

Power Supply
PTO tractor
Tractor power
60 HP
Stabilization
AVR
Power (kVA)
40 kVA
Current
Three-phase
Weight
370 kg

Specific References

MPN
92740
