Suspended disc harrow in V Garto GDSV
Suspended disc harrow in V Garto GDSV

V-shaped suspended disc harrow Garto GDSV

Rating:
(0)
  • Working width: 1400 - 2200 mm
  • No. of discs: 10 - 20
  • Power requirement: 18 - 60 hp
  • Weight: 340 - 475 Kg
En stock
icon Working width PTO
Working width PTO
1400 - 2200 mm
icon Tractor power
Tractor power
18 HP
icon RPM
RPM
540
icon Weight
Weight
340 - 475 Kg
€1,919.00 excl. VAT
- 4%
€1,842.24 excl. VAT
€2,229.11 VAT incl.
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


V-shaped suspended disc harrow Garto GDSV
€2,229.11
Select
Qty

Disc harrow Garto GDSV

The disc harrows Garto GDSV stand out for being designed in V-format and suspended from the bars. The discs are specially manufactured to offer high durability and robustness mainly thanks to the use of high quality materials.

These discs have a diameter of 510 mm and have 4 bearings. The number of discs included in the harrow will depend on the model we choose, ranging from 10 to 20 discs.

As well as the discs, the minimum tractor power required will depend on the model chosen, the highest being 44 - 60 hp. Finally, thanks to its modular structure, the disc harrow Garto GDSV facilitates the user the maintenance work or replacement of parts.

Technical characteristics

Model GDSV140 GDSV180 GDSV220
Working width 1.400 mm 1.800 mm 2.200 mm
No. of discs 10 14 20
Disc diameter 510 mm 510 mm 510 mm
No. of bearings 4 4 4
Weight 340 kg 410 kg 475 kg
Power requirement 18 - 24 hp 25 - 32 hp 44 - 60 hp
Efficiency (Ha/h) 1,0 - 2,2 1,2 - 2,8 1,4 - 4,2
IMPORTANT NOTICE
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement , unless an examination is pending.
259672

Data sheet

Working width PTO
1400 - 2200 mm
Tractor power
18 HP
RPM
540
Weight
340 - 475 Kg

Specific References

mpn
GDSV140
