Rear shredder for DELEKS LINCIONE SPH tractor


  • Working width 1200 - 1800 mm
  • 540 RPM
  • Power 30 - 70 HP
  • Hammers 16 - 28

CARDAN SHAFT INCLUDED

Deleks products take about 15 to 25 days.
En stock
icon Shredder type
Shredder type
Rear shredder
icon Type of cut
Type of cut
Hammers
icon Working width PTO
Working width PTO
120 - 180 cm
icon Tractor power
Tractor power
30 - 70 HP
icon Cardan shaft
Cardan shaft
Including
icon Type of coupling
Type of coupling
Lateral displacement
icon Displacement
Displacement
Hydraulic
icon Robustness
Robustness
Medium-Light
icon Number of hammers
Number of hammers
16 - 28
icon Country of manufacture
Country of manufacture
Italy
icon Weight
Weight
305 - 365 kg
€1,993.54 excl. VAT
€2,412.18 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Finance in 3 months with no interest Pago PAYPAL
Shipments to all Europe
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Rear shredder for DELEKS LINCIONE SPH tractor
€2,412.18
Select
Qty

DELEKS LINCIONE SPH rear-mounted shredder for tractor DELEKS LINCIONE SPH

DELEKS LINCIONE SPH Tractor Rear-mounted ShredderFeatures a hydraulic displacement system designed for efficient management in orchards, vineyards and uncultivated areas. Offering a versatile range, this equipment has 4 models each with adjustable features according to specific needs.

Built for a variety of tasks, this shredder is ideal for both grass cutting and processing branches and pruning waste up to 4-5 cm in diameter, thanks to its sturdy structure made of Swedish SSAB steel.

Its innovative platform design ensures optimal mulching and prevents clogging, while its rotor, built with ARVEDI tube and electronically balanced, offers durability and efficiency, being made of 8 mm thick S355 steel.

Hammers, supported by HARDOX brackets, and the sKF rotor bearings self-aligning skids ensure reliable performance in any application. In addition, its double-folding side skids prevent obstructions during lateral movements, making it a versatile choice for a wide range of waste.

Features

ModelLincione 120 SPHLincione 140 SPHLincione 160 SPHLincione 180 SPH
Working width1200 mm1400.0 mm1600.0 mm1800.0 mm
Overall width1340.5 mm1540.5 mm1740.5 mm1940.5 mm
Cutting height min/max38.0 - 60.0 mm
Weight305.0 kg320.0 kg345.0 kg365.0 kg
Total height1130.0 mm
Tractor power30 - 60 HP30 - 60 HP40 - 60 HP40 - 70 HP
3-point hitchCat. 1 (ø 19.0-22.0mm/ 25.0-28.0mm
Hood height460.00 mm
Distance between the lower points560.0 - 950.0 mm
Number of hammers16202428
Max. cutting diameter40.0 - 50.0 mm
Ground to gearbox spacing540.0 mm
Total length930.0 mm
Plate thickness5.0 + 6.0 mm
Thickness of sheet metal on the sides6.0 mm
Skid thickness6.0 mm
Transmission type-V-beltsV-beltsV-belts
Transmission: GearboxLombarda Ingranaggi Srl (Warranty 3 years)
Transmission: PTO540 r/min
Transmission: direction of rotationSchedule
Transmission: freewheel
Transmission: rotor speed2300 rpm
Transmission: gearbox oilYes / SAE 120 - ISO 72925
Transmission: diameter of upper pulley180.0 mm
Transmission: lower pulley diameter130.0 mm
Transmission: number of Koreas4
Transmission: dimensions of the KoreasBX43
Rotor: diameter115.0 mm
Rotor: bearing type and dimensionSKF 2208-TVH
Rotor: balancingElectronic
Rotor: blade thickness8.0 mm8.0 mm8.0 mm10.0 mm
Hammers: weight820.0 g
Hammers: hole dia15.0 mm
Hammers: base width82.0 mm
Hammers: head width45.0 mm
Hammers: diagonal95.0 mm
Roll: diameter121.0 mm
Roll: sheet thickness5.0 mm
Roll: bearing type and dimensionSKF 6207
CardanCE 4x800 mm + BoltCE 6x1000 mm + BoltCE 6x1000 mm + BoltCE 6x1000 mm + Bolt
Horizontal displacement310.0 mm310.0 mm310.0 mm310.0 mm
Packing dimensions138 x 90 x 80 cm158 x 90 x 80 cm178 x 90 x 80 cm198 x 90 x 80 cm
IMPORTANT NOTICE
Mandatory on the part of the customer, review oil and grease levels prior to start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination.
260376

Data sheet

Shredder type
Rear shredder
Type of cut
Hammers
Working width PTO
120 - 180 cm
Tractor power
30 - 70 HP
Cardan shaft
Including
Type of coupling
Lateral displacement
Displacement
Hydraulic
Robustness
Medium-Light
Number of hammers
16 - 28
Working width (cm)
120 - 129 cm
140 - 149 cm
160 - 169 cm
180 - 189 cm
Country of manufacture
Italy
Weight
305 - 365 kg

Specific References

ean13
8053470238628
mpn
LINCIONE120SPHPTO
New
