Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP
Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP
Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP
Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP
Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP

Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP

Rating:
(0)
  • Working width 1250 - 1800 mm
  • Hammers 12 - 16
  • Belts 5
  • Weight 582 - 718

CARDAN SHAFT INCLUDED

En stock
icon Shredder type
Shredder type
Rear shredder
icon Type of cut
Type of cut
Hammers
icon Working width PTO
Working width PTO
125 - 180 cm
icon Tractor power
Tractor power
30 - 100 HP
icon Cardan shaft
Cardan shaft
Included
icon Type of coupling
Type of coupling
Lateral displacement
icon Displacement
Displacement
Hydraulic
icon Robustness
Robustness
Heavy
icon Reinforced chassis
Reinforced chassis
Yes
icon Number of hammers
Number of hammers
12 - 16
icon Weight
Weight
582 - 718 kg
€3,482.17 excl. VAT
- 7%
€3,238.42 excl. VAT
€3,918.49 VAT incl.
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Hammer Crusher Arizona Tech Reverse Zeppelin 30 - 100 HP
€3,918.49
Select
Qty

Arizona Tech Reverse Hammermill Shredder Zeppelin

The Arizona Tech Reverse hammermill shredder Zeppelin is the ideal solution for efficient shredding of prunings in olive groves and orchards. Its robust and versatile design allows it to adapt to various working conditions, providing exceptional results in every application. With features such as hydraulic gate opening.

This machine facilitates access and handling of the materials to be shredded, optimizing productivity and operator comfort. One of the outstanding advantages of this shredder is its ability to work on both the rear and front three-point linkage of the tractor, thanks to its group that can operate at 540 or 1000 revolutions.

This provides unparalleled flexibility in the field, allowing the user to easily adapt the mulcher to different configurations and terrain requirements. In addition, with top quality hammers, a cast iron freewheel group, adjustable skids and roller, as well as a cardan shaft included.

Features

Model ESTRDESP12RTECH ESTRDESP16RTECH ESTRDESP18RTECH
Working width (mm) 1250 1600 1800
Belts 5 5 5
Hammers 12 14 16
Weight (Kg) 582 690 718
Dimensions (mm) 1470 x 1210 x 1030 1820 x 1210 x 1030 2020 x 1210 x 1030
PTO r/min 540/1000 540/1000 540/1000
Power required (HP) 30/50 80-100 80-100
IMPORTANT NOTICES
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending.
260039

Data sheet

Shredder type
Rear shredder
Type of cut
Hammers
Working width PTO
125 - 180 cm
Tractor power
30 - 100 HP
Cardan shaft
Included
Type of coupling
Lateral displacement
Displacement
Hydraulic
Robustness
Heavy
Reinforced chassis
Yes
Number of hammers
12 - 16
Working width (cm)
120 - 129 cm
160 - 169 cm
180 - 189 cm
Weight
582 - 718 kg
