The GDW40Y/FS3A is a generator designed to provide reliable and efficient performance in a variety of applications. With a rated power of 33.6 kVA / 26.9 kW and a 4TNV98-IGPGE engine, it ensures continuous operation with an autonomy of 12.52 hours at 75% load, ideal for emergency situations or in industrial sectors.
This generator has a Mecc Alte alternator that provides a high efficiency of 87.6%, guaranteeing optimum performance. Its sound level is reduced, reaching only 63 dBA at 7 meters in its soundproof version, which makes it suitable for operating in noise-sensitive environments.
In addition, it has an excellent load capacity, with a consumption of 6.39 L/h at 75% load and an 80 L fuel tank. This model ensures an emergency power of 37.3 kVA / 29.8 kW, sufficient to keep the most demanding loads operational in critical situations.
MODEL | GDW40Y/FS3A |
Frequency | 50 Hz |
Rotational Speed | 1500RPM |
Power Factor | 0.8 ϕ |
Rated Power (KVA/KW) | 33.6 kVA / 26.9 kW |
Emergency Power (KVA/KW) | 37.3 kVA / 29.8 kW |
Motor | |
Autonomy at 75% | 12.52 h |
Consumption at 75% load | 6.39 L/h |
Refrigerant capacity | 4.2 L |
Standard tank capacity | 80 L |
Engine model | 4TNV98-IGPGE |
Number of cylinders | 4 |
Aspiration | Natural |
Oil capacity | 10.5 L |
Displacement | 3319 cc |
Sound Level Soundproof Version | |
Guaranteed sound level (LWA) | 92 dBA |
Sound pressure @ 1 m | 75 dBA |
Sound pressure @ 7 m | 63 dBA |
Alternator Specifications | |
Alternator | Mecc Alte |
Model | ECP32 1S4 C |
Winding | Standard |
Connections | Star Series |
Frequency | 50 Hz |
Voltage | 400 V |
Phases | 3 |
Power factor | 0.8 ϕ |
Emergency power (27ºC) | 41 kVA |
Nominal power (40ºC) | 37.5 kVA |
Efficiency @ 100% | 87.6% |
Type | Brushless |
Poles | 4 |
Voltage tolerance | ±1% |
Class | H |
Protection | IP 23 |
Battery values | |
Battery voltage | 12 V |
Battery capacity | 80 Ah |
Voltage | 400 V |
Frequency | 50 Hz |
Phases | 3 |
Power factor | 0.8 ϕ |
Maximum current | 54 A |
Rated current | 49 A |
Thermomagnetic circuit breaker | 50 A |
Weight and Dimensions | |
Open weight | 603 Kg |
Weight Soundproof Weight | 801 Kg |
Open Dimensions (cm) | 187 x 100 x 119 |
Soundproof Dimensions (cm) | 220 x 102 x 129 |
IMPORTANT NOTICE |
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
The batteries included in some machines are a free gift, so they are exempt from warranty. |
