The ITCPower DG8000SE-LRS electric generator contains inside it a D500E engine with a displacement of 498 cc and has an oil capacity of 1.65 L. It also operates at 3000 RPM and has a rated power of 12 HP.
This machine has a rated power of 6000 W(6.0 kW) and a maximum power of 6300 W(6.3 kW). In addition, it operates at a frequency of 50 Hz and has a voltage of 230 V.
The ITCPower DG8000SE-LRS generator includes an A5-15 alternator with a rated power of 6 kVA and AVR stabilization, and this alternator is single-phase.
| Model | DG8000SE-LRS |
| Voltage | 230 V |
| Maximum Power | 6300 W |
| Nominal Power | 6000 W |
| Outputs | 1 x 16A / 1 x 32A |
| Display | LED6 |
| Battery | 36 Ah |
| DC output | 12 / 8.3 V/A |
| Fuel Capacity | 28 L |
| Consumption 50% load | 22 h |
| Noise level at 7 meters | 72 dBA |
| Engine model | D500E |
| Motor - Rated Power | 12 HP |
| Engine - Revolutions | 3.000 RPM |
| Motor - Starting Mode | Electric |
| Engine - Displacement | 498 cc |
| Engine - Oil Capacity | 1,65 L |
| Alternator - Model | A5-15 |
| Alternator - Rated Power | 6 kVA |
| Alternator - Power Factor | 1 |
| Alternator - Voltage Regulation | AVR / Brush |
| Net Weight | 152 Kg |
| Gross Weight | 168 Kg |
| Product Dimensions | 920x520x840 mm |
| Box Dimensions | 950x570x870 mm |
| IMPORTANT NOTICE |
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
| The batteries included in some machines are a free gift, so they are exempt from warranty. |
