HYUNDAI diesel electric generator DHY8500LEK-T equipped with a 4-stroke air-cooled engine with direct injection, this generator ensures reliable and efficient performance. Its low oil level alarm with automatic engine shutdown protects against damage due to lack of lubrication, ensuring engine durability.
For smooth and quiet operation, the DHY8500LEK-T features a double support base that reduces vibration and a quiet design that minimizes noise. Its generous fuel tank and the ability to run for 10 hours at 50% load make it ideal for long-term applications. In addition, the signal start capability provides convenience and versatility in use.
With additional features such as an overload protector, pre-heat system for trouble-free starting, grounding and 12V DC output, this generator is a complete solution for your power needs. The compact and low-maintenance engine, along with the reduced injection system, ensures efficient and economical operation.
| Gifts |
|
| Frequency | 50 Hz |
| Nominal Power | 5 kW |
| Maximum Power | 5,3 kW |
| Voltage | 230 V |
| Current | 23,9 A |
| Sockets | 2x16A |
| Digital display | LED6 |
| Tank capacity | 12 L |
| Operation at 50% load | 10 h |
| Noise level at 7 Mts; 50% | 72 dBA |
| Battery | 36 Ah |
| Engine Type | Diesel |
| HYUNDAI engine model | D400E |
| Power | 10 HP |
| Starting mode | Electric |
| Displacement | 418 cc |
| Oil capacity | 1,65 L |
| Alternator | A5S |
| Rated power | 5 kVA |
| Power factor | 1 Cos φ |
| Voltage regulation type | AVR |
| Net Weight | 152 Kg |
| Gross Weight | 168 Kg |
| Product Dimensions | 920x520x760 mm |
| Packing Dimensions | 950x570x790 mm |
| IMPORTANT NOTICE |
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
| The batteries included in some machines area free gift, so they are exempt from warranty. |
