Column drill TL 40 FAT
- Rotation inverter
- Tilting table +/- 90º
- Automatic lowering
€5,415.96 VAT incl.
The Fortex FTX 35 TCM2 pillar drill is equipped with a motor made of aluminum that operates at 230 volts and generates 1500 watts of power. This power is harnessed in the 12 speeds of this drill. These speeds range from 150 to 2450 mpm.
The transmission of power from the motor to the drill is done through the use of belts and has a safety switch to open the pulley cover. The table on which the material will be placed is tiltable up to 45 degrees and can be rotated 360 degrees.
The pillar drill is manufactured to comply with all CE standards and therefore includes a safety switch in case of emergency. Finally, I will talk about its weight, which is only 104 kilograms considering its great power.
MODEL | FTX 35 TCM2 |
Power Supply | 230V/F1 |
Power | 1,5 kW - 2 Hp |
Number of speeds | 12 |
Speed | 150 - 2450 m.p.m |
Drill capacity | 32 mm |
Drill-column distance | - |
Morse taper | MT4 |
Drilling depth | 120 mm |
Column diameter | 92 mm |
Table inclination | 45º |
Table dimension | 360X360 mm |
Total height | 1710 mm |
Net/Gross Weight | 104 Kg |
Dimensions | 1430X660X320 mm |
Data sheet
