Manual band saw Ayerbe AY 260 SCI PLUS MN/TX 1100 W
- Power : 1,1 Kw
- Voltage : 230 - 400 V
- Saw blade size : 2460 x 27 x 0,9 mm
€2,371.20 VAT incl.
The MG CY-135-M manual bands aw equipped with a 0.5 Hp motor, this saw guarantees optimal performance in a variety of applications. Its cutting speed of 65 mt/min makes it an ideal choice for projects that require speed and calidad.Con a weight of 65 kg and compact dimensions of 1040x370x1585 mm.
With a working height of 865 mm, the CY-135-M offers comfort during the cutting process. In addition, it is CE compliant, ensuring operator safety and compliance with quality standards. Ease of transport is facilitated by the built-in wheels, allowing the saw to be taken wherever it is needed.
This manual band saw offers impressive cutting capabilities, with the ability to cut round materials up to 150 mm in diameter at 90 degrees, and rectangular dimensions of 160x150 mm in the same configuration. In addition, its versatility is highlighted by the ability to cut at angles of up to 60 degrees, making it an essential tool for workshops and construction projects.
Engine | 0.5 Hp |
Cutting speeds | 65 mt/min |
Working height | 865 mm |
Belt dimensions | 1735x13x0,9 mm |
90º round cutting capacity | 150 mm |
Rectangular 90º cutting capacity | 160x150 mm |
Cutting capacity square 90º | 150x150 mm |
Cutting capacity round 45º | right 100 mm |
Rectangular cutting capacity 45º right 105x125 mm | right 105x125 mm |
Cutting capacity square 45º right | right 100X100 mm |
Cutting capacity round 60º right | right 70 mm |
Rectangular cutting capacity 60º right | right 70x100 mm |
Cutting capacity square 60º right 70X70 mm | right 70X70 mm |
Weight | 65 Kg |
Dimensions | 1040x370x1585 mm |
