Tracked Barrow Bertolini BTR 340 Power 4.4 HP
Tracked Barrow Bertolini BTR 340 Power 4.4 HP

Tracked Barrow Bertolini BTR 340 Honda GCVx 170 OHC 4.4 HP engine

Rating:
(0)
  • Engine Honda GCVx 170 OHC
  • gearbox: 4 speeds (2 forward + 2 reverse)
  • Maximum capacity 350 Kg
  • Power 4.4 HP
En stock
icon Power Supply
Power Supply
Gasoline
icon Load capacity
Load capacity
350 kg
icon Forklift Type
Forklift Type
From Tracked
icon Engine
Engine
Honda
icon Displacement
Displacement
166 cc
icon Power
Power
4.4 HP
icon Engine type
Engine type
4 strokes
icon Gears
Gears
2+2
icon Max. slope
Max. slope
20%
icon Drawer turning
Drawer turning
Manual
icon Transmission type
Transmission type
Gears in an oil bath
icon Type of box
Type of box
Expandable box
icon spin
spin
Assisted
icon Country of manufacture
Country of manufacture
Italy
icon Weight
Weight
140 kg
€3,167.98 excl. VAT
- 4%
€3,041.26 excl. VAT
€3,679.92 VAT incl.
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


Tracked Barrow Bertolini BTR 340 Honda GCVx 170 OHC 4.4 HP engine
€3,679.92
Qty

Tracked Barrow BTR 340 Honda GCVx170 OHC engine

The Crawler Wheelbarrow Bertolini BTR340 K has a Honda GCVx170 engine which provides 4.4HP and 160cc. This model of crawler wheelbarrow features a gearbox with Four speeds, two forward and two back.

This crawler wheelbarrow features a track contact surface of 58cm in length and 17cm in width. It features a Dumper-type loading platform (extendable flatbed). It comes with brakes with expansion and automatic cut-off.

The BTR 340 K Crawler Wheelbarrow It operates with a transmission with gears in an oil bath. It offers a manual discharge and is capable of supporting a load of up to 350 kg. It has a minimum turning radius of 700 mm with a Discharge angle of 45º and a manual flip.

Characteristics

Engine Honda GCVx 170 OHC
Power 4.4 HP 166 cc
Max. capacity. 350 Kg
Gears 4 speeds, 2 forward + 2 reverse
Width 520-900
Maximum tilt in a vacuum 20%
Long 925-1060
Transmission Gears in an oil bath
Minimum turning radius 70 cm
Super contact surface caterpillar 58 cm length – 17 cm width
Weight 140 Kg
Type of box extensible
Download Manual

Carretilla oruga Bertolini BTR 340 Motor Honda GCVx 170-2

Carretilla oruga Bertolini BTR 340 Motor Honda GCVx 170-3

Difference between the oil bath clutch of other brands and the dry multi-disc clutch of Bertolini


Clutch brake in oil bath (Other brands) Inconveniences

  • Hydraulic due to the use of oil.
  • When the machine gets filled with debris, it is more likely to fail.
  • Practical and functional with good maintenance when needed.
  • On its first use, it is necessary to change the oil within a maximum of 40 hours.
  • The engine has a small oil pump that connects to the clutch device and lubricates it, allowing it to function. When this oil is full of debris, the system will stop working and start to fail.
  • In the case of poor maintenance, the machine starts to malfunction. The warranty does not cover the damages, so it will be necessary to take it to the workshop and have it repaired by a professional.
  • There could be oil leaks at certain points of the machine.


Multi-disc dry clutch Bertolini

  • Simpler and more mechanical system with a clutch with brake and a force multiplication system without DHS.
  • This machine is less prone to failures.

IMPORTANT
It is mandatory for the client to check oil levels and lubrication before starting up!

If the merchandise cannot be checked at the time of receipt, it should be noted on the carrier's document that the customer is in agreement pending examination.
