Multifunctional arm crusher for Garto LGA tractor
Multifunctional arm crusher for Garto LGA tractor
Multifunctional arm crusher for Garto LGA tractor

Multifunctional arm crusher for Garto LGA tractor

Rating:
(0)
  • Weight : 250 kg - 280 kg - 315 kg
  • Working width : 1200 mm - 1400 mm - 1600 mm

CARDAN SHAFT INCLUDED

En stock
icon Shredder type
Shredder type
Shredder with side arm
icon Type of cut
Type of cut
Hammers
icon Working width PTO
Working width PTO
120 - 160 cm
icon Tractor power
Tractor power
30 - 60 HP
icon Cardan shaft
Cardan shaft
Included
icon Type of coupling
Type of coupling
Pantograph displacement
icon Displacement
Displacement
Hydraulic
icon Robustness
Robustness
Medium-Light
icon Number of hammers
Number of hammers
20 - 28
icon Weight
Weight
250 - 315 kg
€2,437.13 excl. VAT
- 4%
€2,339.64 excl. VAT
€2,830.97 VAT incl.
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Multifunctional arm crusher for Garto LGA tractor
€2,830.97
Select
Qty

Multifunctional Tractor Arm Shredder Garto LGA

The Multi-function Tractor Arm Shredder Garto LGA is an efficient and versatile implement designed for various agricultural tasks. Its multi-function hydraulic arm offers ample possibilities and versatility in field work.

It features an adjustable rear roller that provides stability and precise control during mulching work. In addition, the adjustable side skids ensure an even, high-precision cut.

Equipped with 3 belts, it ensures smooth and efficient movement of the pulleys, maximizing their performance. The interchangeable hammers allow to adapt to different types of materials and working conditions.

With a 3-point hitch, this mulcher is easily connected to the tractor, facilitating quick and efficient setup. In addition, the mulcher comes with a cardan shaft system included, which facilitates the transfer of power from the tractor, and thanks to its adjustable tailgate, it simplifies the task of cleaning up the mulched debris.

Features

Model LGA125 LGA145 LGA165
Working width 1200 mm 1400 mm 1600 mm
Width 1370 mm 1570 mm 1770 mm
Folding angle +90º / -53º / +90º / -53º +90º / -53º / +90º / -53º +90º / -53º / +90º / -53º
Weight 250 kg 280 kg 315 kg
No. of hammers 20 24 28
No. of belts 3 3 3
PTO speed 540 RPM 540 RPM 540 RPM
Power requirement 30 - 55 hp 35 - 60 hp 50 - 60 hp

IMPORTANT NOTICE
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending.
