Snow plow for tractor Deleks LNS-190-A
Snow plow for tractor Deleks LNS-190-A
Snow plow for tractor Deleks LNS-190-A
Snow plow for tractor Deleks LNS-190-A

Snow plow for tractor Deleks LNS-190-A

Rating:
(0)
  • Tractor power: 25-45 HP
  • Blade width: 1916mm
  • Blade height: 525mm
  • Inclination: 28 degrees
Deleks products take about 15 to 25 days.
En stock
icon Working width
Working width
190 - 199 cm
icon Country of manufacture
Country of manufacture
Italy
€1,096.81 excl. VAT
- 4%
€1,052.94 excl. VAT
€1,274.05 VAT incl.
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


Snow plow for tractor Deleks LNS-190-A
€1,274.05
Qty

Snow Plow for Tractor Deleks LNS-190-A

The Snow Plow for Tractor Deleks LNS-130-A is a tractor attachment compatible with tractors that provide a power between 25 and 45HP. This plow is for front or rear use.

This model of Snow Plow Deleks is designed to remove snow from roads, parking lots, or for companies. It features a robust structure that not only removes snow but also serves as a leveler.

The plow is attached to the tractor with a 3-point hitch of category 1. This can be replaced by a plate or a support for a compact mini-loader. The Deleks LNS-130-A Plow is approved for public roads.

The model of Snow Plow LNS-130-A by Deleks is equipped with two hydraulic outlets. Additionally, this model can be optionally equipped without a hydraulic system. This is for a right to left orientation.

This Snow Plow features 4 anti-shock springs that allow the operator to work with maximum safety. Additionally, it is easy to assemble and use with great comfort. The blade of this model is replaceable.

Features

Weight 141 kg
Total height 830 mm
Tractor power 25 - 45 HP
Total depth 670 mm
Oil pressure min./max 110 - 150 bar
Optional oil flow 18 - 22 l/min
Attachment UNIVERSAL PLATE
Plate dimensions 260*370 mm
Inclination 28°
Float +/- 2°
Blade height 525 mm
Thickness of side reinforcements 8 mm
Shock absorbers 4
Space between ground and plate 270 mm
Blade Steel or rubber
Blade: height 120 mm
Blade: thickness 14 mm
Sharpening: number 1
Sharpening: space between bolts 200 mm
Side lights x
Side skids x
Blade width (inclined) 1705 mm
Hydraulic tubes 2 x 4000 mm / fittings 1.2" AGRI, WP 400 bar
Blade width 1916 mm
Sheet thickness 4 mm
Piston ø/i 50 / 25 mm
Packaging dimension 1916*800*800 mm
258145

Data sheet

Working width
190 - 199 cm
Country of manufacture
Italy

Specific References

EAN-13
8053470231285
New
