The Ayerbe 6000 Electric Generator is a powerful power source with a 7.5 HP, 174 cc KIOTSU KT-190 F engine, which operates with an air cooling system and uses SAE 20W40 CD, CF grade oil.
With a maximum power output of 6,000 W and rated at 5,500 W at 3,000 rpm, this generator provides stable output at a voltage of 230 V and frequency of 50 Hz, ensuring a reliable power supply.
In addition to its robust performance, the Ayerbe 6000 Inverter generator features a soundproof enclosure that reduces the sound level to 89 LwA / 64 LpA at a distance of 7 meters.
Equipped with electric start and a power factor of cos phi 0.8, this generator offers an efficient and quiet solution for various applications, ensuring a stable power supply with minimal noise impact.
| Maximum power | 6.000 W |
| Rated power | 5.500 W |
| R.p.m. | 3.000 r.p.m. |
| Voltage / Frequency | 230 V. / 50 Hz. |
| Soundproof booth | Yes |
| Starter | Electric |
| Power factor | Cos phi 0.8 |
| Noise level | 89 LwA / 64 LpA@7m |
| Motor | |
| Brand | KIOTSU |
| Model | KT-190 F |
| Power | 7.5 HP |
| Displacement | 174 cc |
| Cooling system | Air |
| Engine oil type | SAE 20W40 / IPE grade CD, CF |
| Aspiration | Natural |
| R.P.M. of engine | 3.600 r.p.m. |
| Speed governor | Mechanics |
| Fuel | Gasoline |
| Fuel consumption at 75% | 1.8 L/H |
| Oil capacity | 0,80 L |
| Starting system | Electric |
| Alternator | |
| Brand | AYERBE |
| Model | 6000 |
| Type | Inverter |
| Type of insulation | Class H |
| IP protection | IP 23 |
| Excitation system | Inverter |
| Voltage Tolerance | + - 1% |
| Poles | 2 |
| Voltage / Frequency | 230 / 50 Hz. |
| Type of coating | Standard (without impregnation) |
| Dimensions and Weight | |
| Tank capacity | 13,5 l |
| Autonomy at 75% | 7 hours |
| Weight | 57 kg |
| Dimensions | 638 x 502 x 545 mm |
| Packing volume | 0,03 m³ |
| IMPORTANT NOTICE |
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending. |
| The batteries included in some machines are a free gift, so they are exempt from warranty. |
