Direct gas air heater MASTER BLP 103ET
Direct gas air heater MASTER BLP 103ET

Direct gas air heater MASTER BLP 103ET


  • Post ventilation
  • Overheating protection
  • Heating power: 57-103 kW
  • Adjustable heat level
En stock
icon Power Supply
Power Supply
Gas
icon Startup
Startup
Electric
icon Power
Power
57 - 103 kW
icon Pressure
Pressure
0.75 - 2.0 bar
icon Chassis material
Chassis material
Enameled steel
icon Dimensions
Dimensions
89.5 x 32.4 x 62.4 cm (89.5 x 32.4 x 62.4 cm)
icon Air flow rate
Air flow rate
3260 m3/h
icon Country of manufacture
Country of manufacture
Italy
icon Weight
Weight
22.3 Kg
€842.70 excl. VAT
- 4%
€808.99 excl. VAT
€978.88 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Finance in 3 months with no interest Pago PAYPAL
Shipments to all Europe
Free shipping for Spain (Peninsula)
Qty

Request a quote
close

Request a quote


Direct gas air heater MASTER BLP 103ET
€978.88
Qty

Gas air heater MASTER BLP 103ET with electronic ignition

The gas air heater MASTER BLP 103ET with electronic ignition Combines power and safety, ideal for heating large industrial or commercial spaces.

With a Adjustable heating power between 57 and 103 kW, this team offers a performance of 194,500 to 351,700 Btu/h and 49,000 to 88,600 kcal/h, adapting to different heating needs.

Designed for safe operation, it includes Double solenoid valve, overheating protection and a ionization electrode that continuously monitors the flame.

Furthermore, your system of post ventilation and its motor with thermal protector ensures efficient and reliable operation. The thermostat can be analog or digital, providing flexibility in temperature control.

With a air flow of 3,260 m³/h and a gas consumption of 6.66 kg/h, this heater ensures an even distribution of heat. It is compact with dimensions of 895 x 324 x 624 mm and a net weight of 22.3 kg, facilitating its transportation.

Includes a Pressure limiter and gas piping, ready for immediate use.

Main features

  • Double solenoid valve
  • The ionization electrode continuously checks for the presence of the flame.
  • Post ventilation
  • Pressure limiter and flexible gas hose included
  • Motor with thermal protector
  • Overheat protection
  • Adjustable heat level

Ideal for

  • Agriculture
  • Automobiles
  • Commercial buildings
  • Construction
  • Industrial, factories, and production
  • Rental companies
  • Warehouses and storage facilities

Technical specifications

MODEL BLP 103ET
Calorific power 57-103 kW
Calorific power 194.500-351.700 Btu/h
Calorific power 49,000-88,600 kcal/h
Pressure 0.75 - 2.0 bar
On Electronic
Room thermostat Analog or Digital
Airflow 3,260 m³/h
Fuel consumption 6.66 kg/h
Power Supply electric 220-240/1ph/50 V/Hz
Absorbed power 0.23 kW
Nominal current 1 A
Product dimensions (L x W x H) 895 x 324 x 624 mm
Dimensions with packaging (L x W x H) 940 x 390 x 620 mm
Net weight/gross weight 22.3/27.5 Kg
261765

Data sheet

Power Supply
Gas
Startup
Electric
Power
57 - 103 kW
Pressure
0.75 - 2.0 bar
Chassis material
Enameled steel
Dimensions
89.5 x 32.4 x 62.4 cm (89.5 x 32.4 x 62.4 cm)
Air flow rate
3260 m3/h
Country of manufacture
Italy
Weight
22.3 Kg

Specific References

EAN-13
8053670890992
MPN
4015.027
New
