The Gasoline Electric Generator Pramac MES8000 is a powerful machine available in two models, one with AVR stabilization system and one without. With a simple yet functional control panel, this generator offers commands such as on/off switch, manual start and a fuel key for easy and efficient operation.
This generator is equipped with essential protections, including thermal protection and an oil level alarm, ensuring the safety of the equipment and providing trouble-free operation. In addition, it features a variety of sockets, including a 230V 16A IP54 SCHUKO and a 230V 32A IP44 2P+T CEE, allowing the connection of various devices and equipment.
The Pramac MES8000 is powered by a powerful Honda GX390 engine with an air-cooled system and manual start. With a displacement of 389 cc and a 1.1-liter oil tank, this generator provides a maximum power of 6400 W and a rated power of 5500 W at a frequency of 50 Hz and a voltage of 230 V. With its mechanical speed regulator and 3000 rpm operation, this generator is a robust and reliable solution for all your power needs.
| Model | Without AVR | With AVR |
| Frequency | 50 Hz | |
| Voltage | 230 V | |
| Power factor | 0.9 cos ϕ | |
| Phases | 1 | |
| Maximum power | 6400 W | |
| Nominal power | 5500 W | |
| Engine Brand | Honda | |
| Model | GX390 Recoil | |
| Cooling System | Air | |
| Aspiration | Natural | |
| Speed regulator | Mechanical | |
| Nominal operating speed | 3000 rpm | |
| Fuel | Gasoline | |
| Starting system | Manual | |
| Oil tank | 1.1 l | |
| Displacement | 389 cc | |
| Alternator type | Brushless | With brushes |
| Class | H | |
| IP protection | 23 | |
| Poles | 2 | |
| Voltage tolerance | 2 % | |
| Standard AVR regulation | AVR 520 | |
| Voltage regulation system | Compound | Electronic |
| Fuel consumption at 75% load | 2.14 l/h | 2.16 l/h |
| Autonomy at 75% load | 2.85 h | 2.82 h |
| Fuel consumption at 100% load | 2.87 l/h | |
| Autonomy at 100% load | 2.13 h | |
| Fuel tank capacity | 6.1 l | |
| Dimensions | 750 x 543 x 520 | |
| Dry weight | 61 Kg | |
| Sockets | SCHUKO 230V 16A IP54 | |
| 2P+T CEE 230V 16A IP44 | ||
| IMPORTANT NOTICE |
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
| The batteries included in some machines are a free gift, so they are exempt from warranty. |
Data sheet
Specific References
Battery NOT included in electric start models
