The Branch shredder Negri R280 with its rotor, equipped with re-sharpenable hardened steel blades and reversible mobile hammers of the same material, guarantees a precise and long-lasting shredding process. In addition, it is equipped with a removable fixed refining screen which allows the quality of the final product to be adjusted according to the user's needs.
Its design includes a adjustable hydraulic roller in speed and direction of rotation, a belt of power Supply the steel launching tube is also adjustable in speed and direction, and a rotating launching tube with adaptable ejection depth.
Operator comfort is considered with a large, ergonomic hopper, while the bearing lubrication system ensures smooth, long-lasting operation. The Shredder incorporates a multi-functional control system, the OBS (On Board System), which offers an easy-to-operate complete control and the added benefit of Nostress technology for optimal performance.
 ROTOR : Blades + Hammers |
.jpg "Cuchillas reafilables (acero templado)") Resharpenable blades (hardened steel) |
.jpg "Martillos móviles reversibles (acero templado)") Reversible mobile hammers (hardened steel) |
 Removable fixed refining screen |
 Hydraulic roller adjustable in speed and direction of rotation |
 Tape of power Supply adjustable in speed and direction of rotation |
 Pivoting launching tube with adjustable depth of ejection |
.jpg "OBS - On Board System") OBS - On Board System (Multifunctional control system with Nostress) |
 Lubrication system for bearings |
 Large and comfortable hopper |
 Belt drive with hydrodynamic coupling |
 Homologated road trailer + Adjustable ball joint steering wheel |
| Cutting system | |
| Hammers (hardened steel) | 24 steel hammers |
| Blades (hardened steel) | 2 steel blades |
| Features | |
| Hourly production | 103-18 m3/h |
| Crushing opening | 270 x 150 mm |
| Crushable max. | 150 mm |
| Driving force Honda iGX800 engine | |
| Power | 25 / 18.4 hp/kw |
| Power Supply | Gasoline |
| Engine | Honda iGX800 |
| Fuel consumption | 5.5 l/h |
| Kubota D1105 engine drive force | |
| Power | 26.5 / 19.5 hp/kw |
| Power Supply | Diesel |
| Engine | Kubota D1105 |
| Fuel consumption | 4.8 l/h |
| Technical specifications | |
| Length | 3470 mm |
| Width | 1470 mm |
| Height | 2280 mm |
| Discharge height | 2280 mm |
| Introduction opening | 700 |
| Crushing opening | 1205 x 870 mm |
| Honda engine weight | 700 kg |
| Kubota engine weight | 750 kg |
Chipper accessories Negri:
| IMPORTANT NOTICE |
| Mandatory on the part of the customer, review oil and grease levels prior to start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
