Chipper Negri R225T
The Negri R225T Tractor mounted mulcher, with a cutting system composed of hardened steel blades and hammers, can process branches with a maximum diameter of 90 mm, offering an hourly production of 6-7 m3/h.
Its robustness is complemented by a 160 x 90 mm shredding opening, allowing it to tackle demanding tasks without compromising shredding quality.
This shredder, with a driving force of more than 15 HP, is easily connected to the tractor by means of the three-point hitch, converting the tractor's power into effective shredding action.
Its compact dimensions (1200 mm length, 1700/2220 mm width and 2100/1820 mm height) allow its use in different environments, while its 335 kg weight ensures stability and maneuverability.
- Hydraulic roller adjustable in speed and direction of rotation
- Resharpenable blades (hardened steel)
- Pivoting launching tube and adjustable ejection depth
- Transmission with multiplier group and elastic coupling
- Three-point hitch for tractor - Category 1
- Reversible mobile hammers (hardened steel)
Rotor blades + hammers |
Large and comfortable hopper
|
Bearing lubrication system |
Technical data
| Cutting system |
| Blades |
2 hardened steel blades |
| Hammers |
8 hardened steel |
| Features |
| Hourly production |
6-7 m3/h |
| Crushing opening |
160 x 90 mm |
| Crushable max. |
90 mm |
| Driving force |
| Power |
> 15 / 11 |
| Power Supply |
Three-point hitch for tractor / transverse machine |
| Engine |
tractor |
| Fuel consumption |
/ |
| Technical Specification |
| Length |
1200 mm |
| Width |
1700/2220 mm |
| Height |
2100/1820 mm |
| Unloading height |
1820 mm |
| Feeding height |
1010 mm |
| Crushing opening |
700 x 660 mm |
| Weight |
335 kg |
The mulcher is covered by a 2-year warranty for all European Union countries and original spare parts are available.
Accessories of the mulcher Negri:
- Launching tube extension (400 mm)
- Refining screen kit (Removable fixed refining screen)
- Cardan shaft with CE certified freewheel
| IMPORTANT NOTICE |
|
| It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending. |
