Wood chipper for tractor Garto XB42 150 mm
- Crusher capacity 15 cm.
- Hopper mouth 51×51 cm.
- Rotor inlet mouth 10×25 cm.
€1,588.53 VAT incl.
The Ceccato Olindo Tritone ONE TDF P is a powerful mulcher designed for efficient mulching of branches and garden waste. Its design includes a single hopper of generous dimensions with an opening of 34 cm high and 35 cm wide, allowing easy introduction of branches and debris.
In addition, it features a removable screen to help reduce chunks and an interchangeable sieve that allows the shred size to be adjusted to as little as 0.8 cm (0.8 in.). With a minimum power requirement of 18 HP, this shredder is capable of processing branches up to 50 mm in diameter.
Its belt drive, enameled steel chassis and combined knife and hammer cutting rotor ensure long-lasting and effective performance. With 2 knives and 8 hammers, the rotating movement of the knives guarantees consistent shredding with dimensions from 20 to 30 mm.
Power Supply | PTO |
Exhaust outlet | low |
No. of hoppers | 1 |
Hopper opening height | 34 cm |
Hopper opening width | 35 cm |
Hopper opening dimension | 19 cm |
Grid to reduce chunks | Yes (removable) |
Interchangeable strainer | Yes |
Min. crushed size with screen | 0.8 сm |
Min. power | 18 HP |
Maximum branch diameter | 50 mm |
Transmission type | Belt drive |
Chassis material | Enameled steel |
Cutting rotor type | Combination of blades and hammers |
No. of blades | 2 |
Counter knives | 2 |
No. of hammers | 8 |
Blade movement | rotary |
Grinding dimensions | 20 - 30 mm |
Chimney rotation | manual |
Wheels | 2.50 - 4 " rear wheels |
Product dimensions | 83 x 134 x 106 cm |
Net weight | 100 Kg |
IMPORTANT NOTICE |
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the moment of reception, it must be indicated on the carrier's sheet that the customer is in agreement , unless there is a pending examination. |
Data sheet
Specific References
CARDAN SHAFT INCLUDED
CARDAN SHAFT INCLUDED
