The Motosegadora Bertolini 110 has an Emak engine model K 700 OHV gasoline which provides a power of 5.4 HP and a displacement of 182 cc. It has a conical clutch which is of direct coupling.
This mower model Bertolini also has an oil bath gear transmission. It has a gear shift which is forward. This model has a weight of only 70 kg ( with wheels, movement and bar).
The Motor mower 110 offers a working width of 92cm and has a head with eccentric movement. It has a QuickFit accessory connection as standard, which allows quick and easy change of implements.
It also has an independent power take-off from 1017 revolutions per minute. It has a QuickFit attachment connection as standard that will allow quick and easy implement changes.
The mower also includes a vertically adjustable handlebar with anti-vibration device and 3.50 - 6″ wheels. This model has a weight of only 70 kg ( with wheels, movement and bar).
The main function of this model is to fulfill general cleaning tasks outside the garden. The Model Bertolini 110 is designed for a center-mounted cutting mechanism. It is a lightweight, maneuverable machine designed to meet the user's need.
| Engine | Emak K 700 OHV |
| Power | 5,4 HP |
| Gears | 1 forward speed |
| Working width | 92 cm |
| Head | Eccentric movement |
| Transmission | Gear transmission in oil bath |
| Clutch | Direct coupling |
| PTO | Independent 1017 r/min |
| Accessory connection | QuickFit as standard |
| Weight (with wheels, movement and bar). | 70 Kg |
Difference between the oil bath clutch of other brands and the dry multi-disc clutch of other brands Bertolini
Oil-immersed clutch brake (other brands) Disadvantages
Multi-disc dry clutch Bertolini
|
| IMPORTANT It is mandatory for the customer to check oil and grease levels before start-up ! |
| If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is satisfied unless an examination is pending. |
