Indirect combustion diesel heater MASTER BV 400 with 1 output
The MASTER BV 400 indirect combustion diesel heater with 1 output It is the ideal solution for efficiently and safely heating large spaces. Designed for agriculture, construction, events, and logistics, it ensures clean heat without combustion residues.
With an adjustable heating power between 80 and 110 kW, generates an airflow of 6,200 m³/h, capable of distributing heat evenly up to 50 meters with flexible tubes.
Your deposit of 150 liters offers long hours of autonomy, with a fuel consumption of 7.7 to 10.2 liters per hour, depending on the selected power.
Robust and versatile, it allows the connection of a Ø407 mm tube or two Ø305 mm tubes, making it suitable for ventilation in summer. With dimensions of 2086 x 717 x 1233 mm and a net weight of 200 kg, is equipped with protection IP44 and supports analog or digital thermostats, ensuring precise control in any application.
Ideal for
- Agriculture
- Automobiles
- Commercial buildings
- Construction
- Events and festivals
- Industry and production
- Military and aerospace
- Rental companies
- Transport and logistics
Specifications
| MODEL |
BV 400 |
| Calorific power |
110/80 kW |
| Calorific power |
375,000/237,000 Btu/h |
| Calorific power |
94,600/68,800 kcal/h |
| Fan |
plug type |
| Total air pressure |
500 Pa |
| Possibility of using flexible tubes |
50 m |
| Airflow |
6,200 m³/h |
| Fan motor power |
750/1400 W/rpm |
| Flexible ducts |
2 ducts Ø305mm or 1 duct Ø407mm |
| Thermal jump of the air at the outlet口 |
95°C |
| Ventilation in summer |
Yes |
| Room thermostat |
Analog or digital |
| Chimney pipe |
Ø 150 mm |
| Protection |
IP44 |
| Tank capacity |
150 L |
| Fuel consumption |
10.2 l/h max power - 7.7 l/h min power |
| Nominal current |
6.8 A |
| Power Supply electric |
220-240/1ph/50 V/Hz |
| Product dimensions (L x W x H) |
2086 x 717 x 1233 mm |
| Dimensions with packaging (L x W x H) |
1670 x 710 x 1670 mm |
| Net weight/gross weight |
200/220 Kg |
