The Branch Shredder Negri C13 is a versatile machine available in three engine variants, each with its own power and performance characteristics power Supply. With a cutting system that includes hardened steel blades and hammers, it offers an hourly production capacity of up to 2 tons per hour, converting branches up to 130 mm in crushed material.
Its design with a 162 x 130 mm crushing opening makes it efficient for processing branches of various sizes and its power, which varies between 18.4 and 26.5 hp/kW depending on the engine, ensures consistent and reliable performance.
This shredder stands out for its robustness and efficiency in shredding materials, whether thicker or smaller branches, thanks to its hardened steel blades and hammers that ensure an efficient shredding process.
With engines from renowned brands such as Kohler, Kubota and Honda, it offers options of power Supply with diesel or gasoline, the new system, which provides flexibility in its use and moderate fuel consumption, makes it a reliable option for organic waste management in different environments.
 DISCO : Blades + Counter Blade |
 Reversible mobile hammers (hardened steel) |
 Adjustable counter blade (steel) |
 Large and comfortable hopper |
 Bearing lubrication system |
 Hydraulic roller adjustable in speed and direction of rotation |
| Cutting system | |
| Blades | 2 hardened steel |
| Hammers | 10 hardened steel |
| Counter Blade | 1 |
| Features | |
| Hourly production | 2 t/h2 |
| Crushing opening | 162 x 130 mm |
| Crushable max. | 130 mm |
| Kohler engine power | |
| Power | 26.5/19.5 hp/kW |
| Power Supply | Diesel |
| Engine | KOHLER KDW1003 |
| Fuel consumption | 4.3 l/h |
| Kubota engine drive power | |
| Power | 26.5/19.5 hp/kW |
| Power Supply | Diesel |
| Engine | KUBOTA D1105 |
| Fuel consumption | 4.8 l/h |
| Driving force Honda engine | |
| Power | 25/18.4 hp/kW |
| Power Supply | Gasoline |
| Engine | Honda iGX800 |
| Fuel consumption | 5.5 l/h |
| Technical specifications | |
| Length | 3320/3900 mm |
| Width | 1410 mm |
| Height | 1880/2600 mm |
| Discharge height | 2600 mm |
| Introduction opening | 700 |
| Crushing opening | 810 x 700 mm |
| KOHLER KDW1003 engine weight | 720 kg |
| Engine weight KUBOTA D1105 | 750 kg |
| Engine weight HONDA iGX800 | 680 kg |
| IMPORTANT NOTICE |
| Mandatory on the part of the customer, review oil and grease levels prior to start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination. |
