Wood chipper for tractor Negri R260 longitudinal
Wood chipper for tractor Negri R260

Wood chipper for tractor Negri R260


  • Crushing capacity up to 130 mm
  • Minimum power requirement of 35 HP
  • Hourly production of 10 to 14 m3/h
  • Weight: 660 Kg
En stock
icon Power Supply
Power Supply
PTO tractor
icon Tractor power
Tractor power
minimum 35 HP
icon Cutting rotor type
Cutting rotor type
Blades + hammers
icon Number of blades
Number of blades
2
icon Hammers
Hammers
20
icon Max branch diameter
Max branch diameter
130 mm
icon Number of hoppers
Number of hoppers
1 hopper
icon Safety switch
Safety switch
Yes
icon Transmission type
Transmission type
Belts
icon Drag rotors
Drag rotors
1 Drive rotor
icon Nostress System
Nostress System
Yes
icon Power Supply hydraulics
Power Supply hydraulics
Self-powered
icon Lever of
Lever of
Security
icon Crushing opening
Crushing opening
230 x 130 mm
icon ✔️
✔️
Inverted roller rotation
icon ✔️
✔️
High output
icon Chimney rotation
Chimney rotation
Yes
icon Country of manufacture
Country of manufacture
Italy
€13,477.99 excl. VAT
- 4%
€12,938.87 excl. VAT
€15,656.03 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Finance in 3 months with no interest Pago PAYPAL
Shipments to all Europe
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Wood chipper for tractor Negri R260
€15,656.03
Select
Qty

Tractor branch shredder Negri R260

The Bio shredder for tractor Negri R260 is available in two versions: a longitudinal and a transverse machine, both equipped with a powerful and efficient cutting system. With hardened steel blades and hammers, offers versatility in shredding materials, with up to 20 blades and a shredding capacity of up to 130 mm.

Your hourly production from 10 to 14 m3/h and a 230 x 130 mm shredding opening make it a robust option for intensive work. It requires a minimum power of more than 35 hp, being compatible with tractors thanks to its three-point hitch and belt drive with multiplier group.

It stands out for its multifunctional control system with Nostress, guaranteeing optimal and safe operation, in addition to having a lubrication system for the bearings, prolonging the machine's useful life.

Features

ROTOR | Cuchillas + Martillos

ROTOR : Blades + Hammers
Cuchillas reafilables (acero templado)
Resharpenable blades (hardened steel)
Martillos móviles reversibles (acero templado)
Reversible mobile hammers (hardened steel)
Criba de refinación fija amovible

Removable fixed refining screen
Rodillo hidráulico regulable en velocidad
Hydraulic roller adjustable in speed and direction of rotation
Cinta de alimentación de acero
Tape of power Supply adjustable in speed and direction of rotation
Tubo de lanzamiento giratorio y con profundidad de expulsión regulable
Pivoting launching tube with adjustable depth of ejection
OBS - On Board System
OBS - On Board System (Multifunctional control system with Nostress)
Sistema de lubrificación para cojinetes
Lubrication system for bearings
Tolva amplia y cómoda

Large and comfortable hopper
Transmisión por correas con grupo multiplicador
Belt drive with multiplier group
Enganche tres puntos para tractor - Categoría 1/2
Three-point hitch for tractor - Category 1/2

Technical data

Cutting system
Blades (hardened steel) 2 hammers
Hammers (hardened steel) 20 blades
Features
Hourly production 10 - 14 m3/h
Crushing opening 230 x 130 mm
Crushable max. 130 mm
Driving force
Min. power required >35 hp
Power Supply Three-point hitch for tractor
Technical specifications of the TRANSVERSAL model
Length 1650 mm
Width 2520 mm
Height 2190 mm
Discharge height 2190 mm
Introduction height 800 mm
Introduction opening 1180 x 830 mm
Weight 660 kg
Technical specifications of the LONGITUDINAL model
Length 2815 mm
Width 1400 mm
Height 2190 mm
Discharge height 2190 mm
Introduction height 800 mm
Introduction opening 1180 x 830 mm
Weight 620 kg

Chipper accessories Negri:

  • Launching tube extension (400 mm)
  • Cardan shaft with CE certified freewheel
IMPORTANT NOTICE
Mandatory on the part of the customer, review oil and grease levels prior to start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination.

Links of interest

259291

Data sheet

Power Supply
PTO tractor
Tractor power
minimum 35 HP
Cutting rotor type
Blades + hammers
Number of blades
2
Hammers
20
Max branch diameter
130 mm
Number of hoppers
1 hopper
Safety switch
Yes
Transmission type
Belts
Drag rotors
1 Drive rotor
Nostress System
Yes
Power Supply hydraulics
Self-powered
crusher
Nostress System
Lever of
Security
Crushing opening
230 x 130 mm
✔️
High output
Inverted roller rotation
Chimney rotation
Yes
Country of manufacture
Italy
