Fast disc stands Zeppelin ESGRADARAP 22"
Fast disc stands Zeppelin ESGRADARAP 22"
Fast disc stands Zeppelin ESGRADARAP 22"
Fast disc stands Zeppelin ESGRADARAP 22"
Fast disc stands Zeppelin ESGRADARAP 22"
Fast disc stands Zeppelin ESGRADARAP 22"
Quick tractor disc harrows Zeppelin ESGRADARAP 22"

Quick tractor disc harrows Zeppelin ESGRADARAP 22"


  • Working width: 1400 - 4000 mm
  • Power requirement: 45 - 1000 Hp
  • Disc diameter: 560 - 610 mm
Assembly and set-up INCLUDED
En stock
icon Power Supply
Power Supply
PTO tractor
icon Working width
Working width
1400 - 3000 nm
icon Tractor power
Tractor power
45 - 100 HP
€4,403.26 excl. VAT
- 11%
€3,918.90 excl. VAT
€4,741.87 VAT incl.
Finance in 3 months with no interest Pago KLARNA
Finance in 3 months with no interest Pago PAYPAL
Shipments to all Europe
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Quick tractor disc harrows Zeppelin ESGRADARAP 22"
€4,741.87
Select
Qty

Fast disc harrows Zeppelin

The Disc harrows Zeppelin are attached to tractors to provide the power to operate its double row of discs, which are used to 560 mm or 22 inches in diameter.

Discs, which at the time of purchase you can choose how many you want, having 9 models that go from 10 discs to 24 discs, the working width and weight are changed accordingly. It also includes a rear roller.

Features

Models ESGRADARAP140Z ESGRADARAP160Z ESGRADARAP180Z
Weight (kg) 570 670 770
Working width (mm) 1400 1600 1800
Working depth (mm) 160 160 160
Number of discs 10 12 14
Disc diameter (mm) 560 560 560
Disc diameter (inches) 22" 22" 22"
Dimensions (cm) 155 x 215 x 133 175 x 215 x 133 195 x 215 x 133
Power required (Hp) 45 50 55
Models ESGRADARAP200Z ESGRADARAP220Z ESGRADARAP250Z
Weight (kg) 870 930 1100
Working width (mm) 2000 2200 2500
Working depth (mm) 160 160 160
Number of discs 16 18 20
Disc diameter (mm) 560 560 560
Disc diameter (inches) 22" 22" 22"
Dimensions (cm) 215 x 215 x 130 235 x 215 x 130 265 x 215 x 133
Power required (Hp) 65 80
Models ESGRADARAP270Z ESGRADARAP300Z ESGRADARAP300ZZ
Weight (kg) 1200 1300 1300
Working width (mm) 2700 3000 3000
Working depth (mm) 160 160 160
Number of discs 22 22 22
Disc diameter (mm) 560 560 660
Disc diameter (inches) 22" 22" 22"
Dimensions (cm) 285 x 215 x 133 315 x 215 x 133 315 x 215 x 133
Power required (Hp) 90 100 100

Specifications

  • FROM 10 to 24 AMA DISCS 560 mm diameter - THICKNESS 4 mm
  • INCREASED DISK ANGLE.
  • INTEGRATED REINFORCED BEARINGS.
  • Double row of discs with a diameter of 560 mm (22 inches)
  • Independent shock absorbers
  • Rear roller
  • Harrows mounted upside down from the first row for weeding or different types of crops
  • Increased angle of attack of the working discs.
  • Maintenance-free bearing supports.
  • Side screens that prevent spillage from one side to the other.
  • Rear tubular axle.
  • Automatic ABS traction arm (without pins).
IMPORTANT NOTICE
Mandatory on the part of the customer, review oil and grease levels prior to start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement except for pending examination.
This tractor disc harrow includes a standard roller, allows you to request, with a surcharge, a roller
Packer compatible with ESGRADARAP250Z, ESGRADARAP270Z and ESGRADARAP300Z through our customer service.
