  • Working width 1300 - 1800 mm
  • Number of blades: 17 - 23
  • Weight: 58 - 70 kg
Deleks products take about 15 to 25 days.
En stock
icon Country of manufacture
Country of manufacture
Italy
€1,368.03 excl. VAT
€1,655.32 VAT incl.
Shipments to all Europe
Free shipping for Spain (Peninsula)
Select
Qty

Request a quote
close

Request a quote


Brushcutter head blades Y Deleks ARK
€1,655.32
Select
Qty

Hydraulic cutter bar Deleks HRD

80cm blade shredder, brush cutter for mini excavators 1.0-2.0 ton - DELEKS® - For brambles, bushes, ditches. Hydraulic motor Made in Italy - 2 years warranty.

Hydraulic brushcutter for mini excavator 1.0-2.0 ton.
For brambles, bushes, ditches, banks, embankments, branches.

Hitch dimensions: see pictures (as an alternative we can make an ad hoc hitch under drawing, with additional production cost).

Operating machine requirements for operation:

  • It is preferable to have a double pump
    • 1 for the base tracked
    • 1 for the services (pump of at least 25/30 l/min)
  • The rotation of the blades is from both directions (it is necessary to have the pedal with double effect).
  • The pump needs a third pipe for the drainage that goes in discharge in the tank.

Documentation delivered with the machine:

  • Invoice or tax receipt
  • CE conformity
  • User's manual

Characteristics

Model ARK-80 ARK-100 ARK-110
Working width 800 mm 1000 mm 1100 mm
Total width 1020 mm 1220mm 1320 mm
Cutting height min/max 20 - 80 mm
Weight 100 kg 110 kg 120 kg
Hood height 360 mm
Max. cutting diameter 30 mm
Sheet thickness 4 mm
Transmission: rotor speed 1500 r/min
Rotor: diameter 108 mm
Rotor: bearing type and dimension UC207-6007
Rotor: balancing Electronic
Rotor: blade thickness 8 mm
Roll: diameter 102 mm
Roll: sheet thickness 4 mm
Roll: bearing type and dimension φ25
Oil pressure min./max 120 - 150 bar
Optimal oil flow 25 - 30 l/min
Hood length 650 mm
No. of blades 32 40 44
Slats: weight 330 g
Packing dimensions 102 x 60 x 50 cm 122 x 60 x 50 cm 132 x 60 x 50 cm
IMPORTANT NOTICE
It is mandatory for the customer to check oil and grease levels before start-up. If it is not possible to check the goods at the time of receipt, it must be indicated on the carrier's sheet that the customer is in agreement unless an examination is pending.
